مواصفات الأبواب الحديد
مواصفات الباب
تشطيب ايبوكسي برايمر( MD9 ) :
STEEL DOOR LEAF (NON FIRE RATED)
THICKNESS: 45 mm ± 1 mm
.Material: Galvanized Steel Sheet 1.2 mm thk
Core: Polyurethane Foam @ 35 kg /Ch.M. with One Vertical Stiffener spot welded to the
.face sheets at center only
.Door Leaf Edges: With Mechanical Interlocking vertical hairline seam
مواصفات الضلفة
تشطيب ايبوكسي برايمر ( OMD1 ):
STEEL DOOR LEAF (NON FIRE RATED)
THICKNESS: 45 mm ± 1 mm
.Material: Galvanized Steel Sheet 1.2 mm thk
.Core: Polyurethane Foam @ 35 kg /Cu.M with One Vertical Stiffener spot welded
مواصفات الحلق
تشطيب ايبوكسي برايمر (MF033) :
Type: C-SI (C-Type Slide In)
.Material: Galvanized Steel Sheet 1.5 mm thk
.Joint: Welded Miter Joint
.Profile Dimension: STANDARD (Max. Profile Depth 240 mm)
.Flashing: 1.2mm thk Steel Flashing is included (Std. Profile)
.Sliding guide: Heavy duty U channel is included
.Sliding Mechanism: Not included
الحلق مواصفات
تشطيب ايبوكسي برايمر (MF67 / MF68)
Type: SR1-SI/DR1-SI (Single / Double Rebate Slide In)
.Material: Galvanized Steel Sheet 1.5mm thick for SD / 2.00mm thick for DD
.Joint: Welded Miter Joint
Profile Dimension: AFKAR STANDARD (Max. Profile Depth 240 mm), Unless / Otherwise Specified In Our BOQ
